TS-CE36-84WE2
Efficiency, durability, and aesthetics are paramount in commercial lighting. Introducing the Commercial Garage LED Batten Light 1200mm, a revolutionary lighting solution designed specifically for industrial and commercial environments, particularly garages. This state-of-the-art fixture combines cutting-edge LED technology with a sleek design, providing unparalleled illumination and reliability. Let's delve deeper into the features, benefits, and applications of this exceptional product.
 |
 |
| Code | TS-BA24WK | TS-BA40WK | TS-BA50WK | TS-BA60WK |
|---|---|---|---|---|
| Rated Power | 24W | 40W | 50W | 60W |
| Length | 600MM(2ft) | 1200MM(4ft) | 1500MM(5ft) | 1500MM(5ft) |
| Efficiency | 120-130lm/W | 120-130lm/W | 120-130lm/W | 120-130lm/W |
| Lumens | 2880lm +/-5% | 4800lm +/-5% | 6000lm +/-5% | 7200lm +/-5% |
| Beam Angle | 160° | 160° | 160° | 160° |
| IP Rate | IP66 | IP66 | IP66 | IP66 |
| IK | IK10 | IK10 | IK10 | IK10 |
| Size | L600x80x45MM | L1200x80x45MM | L1500x80x45MM | L1500x80x45MM |
| Code | TS-BA24WKH | TS-BA40WKH | TS-BA50WKH | TS-BA60WKH |
|---|---|---|---|---|
| Rated Power | 24W | 40W | 50W | 60W |
| Length | 600MM(2ft) | 1200MM(4ft) | 1500MM(5ft) | 1500MM(5ft) |
| Efficiency | 150-160lm/W | 150-160lm/W | 150-160lm/W | 150-160lm/W |
| Lumens | 3600lm +/-5% | 6000lm +/-5% | 7500lm +/-5% | 9000lm +/-5% |
| Beam Angle | 160° | 160° | 160° | 160° |
| IP Rate | IP66 | IP66 | IP66 | IP66 |
| IK | IK10 | IK10 | IK10 | IK10 |
| Size | L600x80x45MM | L1200x80x45MM | L1500x80x45MM | L1500x80x45MM |
| Products Name | commercial garage LED batten light 1200mm |
|---|---|
| Body Color | Slivery |
| Reflector color | Milky |
| Materials | Aluminum Body+ PC Cover (anti-UV, UL94-V2,light transmittance 82-85%) |
| IP Rate | IP66 |
| IK Rate | IK10 |
| Linkable | Available (Max 15pcs Linkable) |
| Flicker Free | Available |
| Installation | Surface / Suspended installation |
| Certificates | CE-EMC, CE-LVD, RoHS, FCC, C-tick |
| Working Voltage | 220-240VAC / 100-277VAC |
|---|---|
| Frequency | 50/60Hz |
| Power Factor(PF) | >0.9 |
| Driver Brand | Constant Current Driver |
| Dimmable | Non-DIM / 0-10V / Dali /Pushing Dimming |
| Total Harmonic Distortion(THD) | ≤15% |
| Color Temperature | 27/30/40/45/50/60K Warm White/Neutral White/ Day White/ Cool White |
|---|---|
| Lighting Efficiency | 120-160lm/W |
| Chip Brand | Bridgelux, Epistar, Lumileds Or Other |
| Color Render Index | Ra>80 |
| SDCM | <5 |
| Anti Glare | Yes, (UGR<19) |
| Flicker Free | Yes |
| Ambient Humidity | 10%~90% |
|---|---|
| Ambient Temp. | -20 ~ 50℃ |
| Storage Temp. | -30 ~ 80℃ |
| Working Temp. | < 60℃ (Ta=25℃) |
| Life Span | >50000 Hours (LM80) |
| Warranty | 3 Years |
The Commercial Garage LED Batten Light 1200mm is ideal for a multitude of applications, including:
Automotive Garages: Provide clear, shadow-free lighting for mechanics to work efficiently.
Warehouses and Storage Facilities: Illuminate large areas effectively, improving safety and productivity.
Workshops and Industrial Spaces: Ensure precise visibility for intricate tasks and machinery operations.
Sport Facilities and Gyms: Create a vibrant, well-lit atmosphere for sports and fitness activities.
Commercial Buildings: Enhance the aesthetic appeal and functionality of corridors, stairwells, and lobbies.
