TS-DO2535WM
Introduction
In the realm of modern interior design, lighting plays a pivotal role in setting the ambience and functionality of any space. Among the myriad lighting options available, Linear LED Ceiling Lights – Surface Mounted stands out for its sleek design, energy efficiency, and versatile applications. These lights are engineered to blend aesthetics with performance, making them an ideal choice for both residential and commercial settings.
 |
 |
| Code | TS-L6060A12 | TS-L6060A15 | TS-L6060A18 | TS-L6060A20 | TS-L6060A24 |
|---|---|---|---|---|---|
| Rated Power | 48W | 60W | 72W | 80W | 96W |
| Length | 1200MM/4ft | 1500MM/5ft | 1800MM/6ft | 2000MM/6.5ft | 2400MM/8ft |
| Function | Linkable | Linkable | Linkable | Linkable | Linkable |
| Efficiency | 110lm/W | 110lm/W | 110lm/W | 110lm/W | 110lm/W |
| Lumens | 5280lm+/-5% | 6600lm+/-5% | 7920lm+/-5% | 8800lm+/-5% | 10560lm+/-5% |
| Beam angle | 100° | 100° | 100° | 100° | 100° |
| Cover | Milky/ Prism | Milky/ Prism | Milky/ Prism | Milky/ Prism | Milky/ Prism |
| UGR | <19 | <19 | <19 | <19 | <19 |
| Size | 6x6x120CM | 6x6x150CM | 6x6x180CM | 6x6x200CM | 6x6x240CM |
| Mounting type | Suspended /Surface | Suspended /Surface | Suspended /Surface | Suspended /Surface | Suspended /Surface |
| Products Name | linear led ceiling lights surface-mounted |
|---|---|
| Body Color | Sandy White / Sandy Black |
| Diffuser | Prismatic diffuser / Milky Diffuser |
| Materials | Aluminum Body + Prismatic diffuser |
| Linkable | YES (Max 20pcs 1.5M linkable ) |
| Beam Angle | 100° |
| IP Rate | IP44 |
| Anti-glare | Yes |
| UGR | <19/22 |
| Flicker Free | Yes |
| Installation | Suspended, Surface mounted |
| Certificates | CE-EMC, CE-LVD, RoHS, FCC, C-tick |
| Working Voltage | 220-240VAC / 100-277VAC |
|---|---|
| Frequency | 50/60Hz |
| Power Factor(PF) | >0.9 |
| Driver Brand | Philips / Osram |
| Dimmable | Non-DIM / 0-10V / Dali / Push Dimming |
| Total Harmonic Distortion(THD) | ≤15% |
| Colour Temperature | 27/30/40/45/50/60K Warm White/Neutral White/ Day White/ Cool White |
|---|---|
| Lighting Efficiency | 100-110lm/W |
| Chip Brand | Bridgelux, Epistar, Lumileds Or Other |
| Color Render Index | Ra>80 |
| SDCM | <5 |
| Anti Glare | Yes, (UGR<19) |
| Flicker Free | Yes |
| Ambient Humidity | 10%~90% |
|---|---|
| Ambient Temp. | -20 ~ 50℃ |
| Storage Temp. | -30 ~ 80℃ |
| Working Temp. | < 60℃ (Ta=25℃) |
| Life Span | >50000 Hours (LM80) |
| Warranty | 3 Years |
