parking garage 4ft LED batten light fittings

No.TS-BA30405060WI/IH

Discover the 4ft LED Batten Light Fittings in the parking garage, designed for optimal illumination and energy savings in parking facilities. With Fe LED technology, durable construction, and smart control options, these lights enhance safety, reduce costs, and contribute to sustainability. Ideal for new constructions and retrofits, our lights offer a sleek design and long-lasting performance. Contact us today for more information and quotes!

Power:

30W-2ft

40W-4ft

50W-5ft

60W-5ft

Get The Latest Quote

Add to Quote List View Quote List

Description

Comprehensive Introduction to Parking Garage 4ft LED Batten Light Fittings

Overview

In the realm of modern parking garage lighting, efficiency, durability, and aesthetic appeal are paramount. You are introducing the Parking Garage 4ft LED Batten Light Fittings, a cutting-edge solution designed to illuminate even the darkest corners of your parking facility while ensuring significant energy savings and minimal maintenance. This advanced lighting system combines the latest LED technology with a sleek design tailored specifically for the demanding environment of parking garages.

Products Information

parking garage 4ft LED batten light fittings

Code	TS-BA30WI	TS-BA40WI	TS-BA50WI	TS-BA60WI
Rated Power	30W	40W	50W	60W
Length	600MM(2ft)	1200MM(4ft)	1500MM(5ft)	1500MM(5ft)
Efficiency	120-130lm/W	120-130lm/W	120-130lm/W	120-130lm/W
Lumens	3600lm +/-5%	4800lm +/-5%	6000lm +/-5%	7200lm +/-5%
Beam Angle	160°	160°	160°	160°
IP Rate	IP65	IP65	IP65	IP65
IK	IK10	IK10	IK10	IK10
Function	Twistable End Cap	Twistable End Cap	Twistable End Cap	Twistable End Cap
Size	L600xW77xH68MM	L1200xW77xH68MM	L1500xW77xH68MM	L1500xW77xH68MM

High Efficiency Version

Code	TS-BA30WIH	TS-BA40WIH	TS-BA50WIH	TS-BA60WIH
Rated Power	30W	40W	50W	60W
Length	600MM(2ft)	1200MM(4ft)	1500MM(5ft)	1500MM(5ft)
Efficiency	150-160lm/W	150-160lm/W	150-160lm/W	150-160lm/W
Lumens	4500lm +/-5%	6000lm +/-5%	7500lm +/-5%	9000lm +/-5%
Beam Angle	160°	160°	160°	160°
IP Rate	IP65	IP65	IP65	IP65
IK	IK10	IK10	IK10	IK10
Function	Twistable End Cap	Twistable End Cap	Twistable End Cap	Twistable End Cap
Size	L600xW77xH68MM	L1200xW77xH68MM	L1500xW77xH68MM	L1500xW77xH68MM

Common Data

Products Name	parking garage 4ft LED batten light fittings
Body Color	Slivery
Reflector color	Milky
Materials	Aluminum Body + PC cover (anti-UV, UL94-V2,light transmittance 82-85%)
IP Rate	IP65
IK Rate	IK10
Linkable	Available
Flicker Free	Available
Function	Twistable End Cap & Quick Installation
Installation	Surface / Suspended installation
Certificates	CE-EMC, CE-LVD, RoHS, FCC, C-tick

Electrical Data

Working Voltage	220-240VAC / 100-277VAC
Frequency	50/60Hz
Power Factor(PF)	>0.9
Driver Brand	Constant Current Driver
Dimmable	Non-DIM / 0-10V / Dali /Pushing Dimming
Total Harmonic Distortion(THD)	≤15%

Lighting Source Data

Color Temperature	27/30/40/45/50/60K Warm White/Neutral White/ Day White/ Cool White
Lighting Efficiency	120-160lm/W
Chip Brand	Bridgelux, Epistar, Lumileds Or Other
Color Render Index	Ra>80
SDCM	<5
Anti Glare	Yes, (UGR<19)
Flicker Free	Yes

Application

Ambient Humidity	10%~90%
Ambient Temp.	-20 ~ 50℃
Storage Temp.	-30 ~ 80℃
Working Temp.	< 60℃ (Ta=25℃)
Life Span	>50000 Hours (LM80)
Warranty	3 Years

Benefits for Your Business

Increased Safety: Brighter, more consistent lighting enhances visibility, reducing accidents and making your parking garage a safer environment for all users.
Cost Savings: Significant energy savings and reduced maintenance costs contribute to long-term financial benefits, making these lights a wise investment for any facility manager.
Environmental Impact: By reducing energy consumption and waste, these lights help your business contribute to sustainability efforts and appeal to eco-conscious customers.
