TS-DO2535WM
In the realm of modern lighting solutions, the waterproof recessed LED downlight stands as a testament to innovation and practicality. Designed to seamlessly integrate into various environments, these lights not only enhance the aesthetic appeal of your spaces but also ensure optimal illumination while maintaining a high level of durability and energy efficiency. This comprehensive guide delves into the intricacies of our waterproof recessed LED downlights, highlighting their key features, benefits why they are the ideal choice for your lighting needs.
 |
 |
 |
| Code | TS-DO12WPE | TS-DO15WPE | TS-DO20WPE | TS-DO30WPE |
|---|---|---|---|---|
| Rated Power | 12W | 15W | 20W | 30W |
| Cut-Out | D 75MM | D 95MM | D 125MM | D 155MM |
| Input Current | 55mA@220V | 68mA@220V | 113mA@220V | 136mA@220V |
| Lumens | 1200lm +/-5% | 1500lm +/-5% | 2000lm +/-5% | 3000lm +/-5% |
| Beam Angle | 24°, 45°, 60° | 24°, 45°, 60° | 24°, 45°, 60° | 24°, 45°, 60° |
| Size | D85xH70MM | D110xH78MM | D135xH91MM | D180xH106MM |
| Code | TS-DO40WPE | TS-DO50WPE | TS-DO60WPE | TS-DO80WPE |
|---|---|---|---|---|
| Rated Power | 40W | 50W | 60W | 80W |
| Cut-Out | D 155MM | D 155MM | D 220MM | D 220MM |
| Input Current | 182mA@220V | 227mA@220V | 273mA@220V | 364mA@220V |
| Lumens | 4000lm +/-5% | 5000lm +/-5% | 6000lm +/-5% | 8000lm +/-5% |
| Beam Angle | 24°, 45°, 60° | 24°, 45°, 60° | 24°, 45°, 60° | 24°, 45°, 60° |
| Size | D180xH106MM | D180xH106MM | D242xH120MM | D242xH120MM |
| Products Name | Waterproof Recessed LED Downlights |
|---|---|
| Body Color | Sandy White / Sandy Black |
| Reflector Color | Matte Black/ Matte White / Matte Silver/ Gun Black |
| Materials | Aluminum Body + Lens / PC cover |
| IP Rate | IP65 |
| Add Honeycomb | Not Available |
| Anti glare | Yes |
| UGR | <19 |
| Flicker Free | Yes |
| Installation | Recessed Type |
| Certificates | CE-EMC, CE-LVD, RoHS, FCC, C-tick |
| Working Voltage | 220-240VAC / 100-277VAC |
|---|---|
| Frequency | 50/60Hz |
| Power Factor(PF) | >0.9 |
| Driver Brand | Lifud / Eaglerise / Kegu / Philips / Osram |
| Dimmable | Non-DIM / TRIAC / 0-10V / Dali / Push Dimming |
| Total Harmonic Distortion(THD) | ≤15% |
| Color Temperature | 27/30/40/45/50/60K Warm White/Neutral White/ Day White/ Cool White |
|---|---|
| Lighting Efficiency | 100lm/W (COB) , 120lm/W(SMD) |
| COB chip Brand | Bridgelux / CREE / Philips / Osram COB / Epistar SMD |
| Color Render Index | Ra>80 / Ra>90 / Ra>95 |
| SDCM | <5 |
| Anti Glare | Yes (UGR<19) |
| Flicker Free | Yes |
| Ambient Humidity | 10%~90% |
|---|---|
| Ambient Temp. | -20 ~ 50℃ |
| Storage Temp. | -30 ~ 80℃ |
| Working Temp. | < 60℃ (Ta=25℃) |
| Life Span | >50000 Hours (LM80) |
| Warranty | 3 Years |
